Alfred Schellenberg GmbH shall not be liable for any consequential damage, pro-
perty damage and personal injury due to improper use.
According to EN 13659, it must be ensured that the displacement requirements as
per EN 12045 are met. When unrolled, the displacement at the lower edge must be
at least 40 mm at an upward-directed force of 150 N. It must be ensured that the
travel speed of the hanging must be less than 0.2 m/s in the last 0.4 m.
TECHNICAL DATA
Power supply unit operating voltage 230 V / 50 Hz
Rated power 29 W
Standby power < 0.7 W
Power supply unit 24 V DC / 1.2 A
Torque MdN = 2,5 Nm
Max. speed 34 rpm
Max. tensile force /
initial tensile force
16 kg
Final tensile force 7 kg at belt
Short-time operation 5 minutes
Protection class III
Enclosure rating IP 20 (for dry rooms only)
Positioning accuracy 5 mm
Number of switching times 2 (UP and DOWN)
Automatic solar control
setting range
3,000 bis 10,000 Lux
Permissible ambient temperature 0-40 °C
