TECHNICAL DATA
Smart DRIVE L / Smart DRIVE XL
Item no. 60923 / 60924
Operating voltage 220 V–240 V AC 50/60 Hz
Rated output 200 W / 245 W
Standby consumption 5 W / 7 W
Maximum force 600 N / 1000 N
Speed 0.15 m/s
Lighting LED 12 V DC
Burn time 3 min.
Radio frequency 868.4 MHz
Signal strength max. 10 mW
Ambient temperature -20°C to +40°C
Max. door size 10 m² / 14 m²
Protection class IP 20. Only for dry indoor rooms.
Protection class
Handheld transmitter
Item no. 60930 / 60931
Model/type Wireless handheld transmitter, 868 2-channel/4-channel
Radio frequency 868,4 MHz
Signal strength max. 10 dBm / 10 mW
Power supply 3 V DC
Battery type CR2032 (lithium battery)
Protection class IP 20. Only for dry indoor rooms.
Ambient temperature -10°C to +55°C
LEGEND FOR SCOPE OF DELIVERY
A Rail incl� chain
C Central rails
D End rail
E Wall mount
F Garage door drive
G Drive adapter
I M6 hexagon nut
J “Long” collar stud with cotter pin
L Ceiling mounting bracket
M M6 hexagon screw
N Door mounting piece
P “Short” collar stud with cotter pin
Q Manual door release cable
S Drilling screws
T Handheld transmitter
U Power cord
V
W Interior switch
Light barrier
Fastening material for the door and wall is not included in the scope of delivery�
