TECHNICAL DATA
Power supply 230V AC / 50Hz
Switching current 3A / 230 VAC inductive load
Protection type IP 20
Protection class II after the respective
installation
Switching time 180 seconds
permissible
temperature range
0° C to 50° C
Power reserve approx. 5 hours
Accuracy approx. +/- 1 seconds / day
Standby consumption* 0.5 watts
Mounting type ush mount wall box,
Ø 60 mm, hole spacing, min.
25 mm depth
on-wall mountable with
corresponding housing
* The clock is always ready for operation to execute the set switching times and
additional functions�
