6
Probe (pressure switch). It is a little steel device, mounted on the aluminum structure. It is
connected to the computer throw the cables PS / PS . Its function is to check the cycling of the
machine .
Computer box . It is an external unit. It has to be installed relatively close to the watermaker, in
a position protected from water. It is connected to the remote panel and controls the functions of
the watermaker automatically.
The microswitches P1and EV allow the direct command of the pump the electrovalve
respectively. They can be used, as an emergency solution, for starting the watermaker in case of
total failure of the electronic computer. In normal condition they have to be switched off.
Depressurization valve
Reset valve
Positioner
Remote panel cable
connector
Emergency
microswitch
Electric
connections
