4 of 4
Preliminary copy – for evaluation - not released
8) Remove alignment nut/pin bracket.
9) Support the Tubehead
10) Remove the lock bracket.
11) Slide the Tubehead down until free.
12) Replace Tubehead by reversing the steps.
13) When Tubehead is replaced and wiring is correct then turn the
machine ON and retest as above.
Support the
Tubehead weight
and remove the lock
bracket
