Schindler CUBE PLUS AP - Technical Specifications; External Connections; Modem Performances

1 - Foreword
CB3 Basic EU - User Guide
4
2 - Technical features
2.1 PHYSICAL DESCRIPTION
SIZES
150mm x 134 mm x 48 mm (whole)
WEIGHT
311g
OPERATING TEMPERATURE
From –10°C to +65°C
HUMIDITY
From 0 to 95% not condensed
2.2 EXTERNAL CONNECTIONS
TELEPHONY
2-pole external terminal
LAN (4)
RJ45 connectors
RS232 (2)
RJ11 female connectors
USB
Type A USB
ANTENNA (2)
SMA female connector
POWER SUPPLY INPUT
12 ÷ 24 Vdc, 0.8 A max
RS485
3-pole external screw terminal
AUX-IN/OUT
4-pole external screw terminal
RST
Push Button
2.3 CONSUMPTION
AVERAGE CONSUMPTION
Standby/Typical application: 3,12W
Maximum application: 6,52W
2.4 FEATURES OF THE TELEPHONE (TA) CONNECTION POINT
INTERFACE
2-pole external terminal
CALL MODE
Originated call (MOC); Terminated call (MTC)
INPUT DIALLING
DTMF
COMPLIANT WITH
ETSI ES 201 970 V1.1.1
CALL CURRENT LEVEL (RING)
35Vrms ± 10% + 38Voffset
CALL CURRENT FREQUENCY
25Hz ± 5%
CALL CURRENT MODULATION
1,0s emission; 4,0s silence
LOCAL TONE MODULATION ACCURACY (EMISSION / SILENCE)
± 1%
SHORT CIRCUIT CURRENT
>35mA
TELEPHONE CONNECTION POINT CHARACTERISTIC IMPEDANCE
750Ω // 150nF + 270Ω
MAXIMUM TELEPHONE LINE LENGTH
500 meters (depending on the number of connected devices)
2.5 FEATURES OF THE LAN CONNECTION POINT
INTERFACE
4 x RJ45 (LAN 10/100)
COMPATIBILITY
IEEE 802.3
2.6 FEATURES OF THE RS232 CONNECTION POINT
INTERFACE
RJ11 CONNECTOR
COMPATIBILITY
RS232
2.7 FEATURES OF THE RS485 CONNECTION POINT
INTERFACE
3-pole external screw terminal
COMPATIBILITY
RS485
2.8 FEATURES OF THE USB CONNECTION POINT
INTERFACE
Type A connector
COMPATIBILITY
USB 2.0
CUBE PLUS XE
2.9.1 MODEM PERFORMANCES
BAND
FDD B1/B3/B7/B8/B20/B28A;
WCDMA B1/B3/B8; GSM/EDGE B3/B8
RF power
2G (GSM): - LB: Class 4(2W, 33dBm ± 2dB)
Class E2(0.5W, 27dBm ± 3dB
@EDGE)
HB: Class 1(1W, 30Bm ± 2dB)
Class E2(0.4W, 26dBm +3/-4 dB
@EDGE)
3G (WCDMA): Class 3(0.25W, 24dBm +1,7/-
3,7 dB)
4G (FDD & TDD): Class 3(0.2W, 23dBm ± 2,7
dB @1RB))
DATA TRANSFER
LTE category 4
LTE FDD: Max 150Mbps (DL)/Max 50Mbps
(UL)
DC-HSPA+ 42 Mbps)
Modulation
E-GSM/DCS: GMSK, 8PSK
UMTS: QPSK
LTE: QPSK, 16 QAM and 64 QAM
2.10.1 BLUETOOTH
Frequency range
2402 ÷ 2480 MHz
RF power
BLE: 8.2 dBm
Modulation
GFSK
