1 - Foreword
CB3 Basic EU - User Guide
5
CUBE PLUS XA
2.9.2 MODEM PERFORMANCES
BAND
FDD B1/B2/B3/B4/B5/B7/B28A;
WCDMA B1/B2/B4/B5;
GSM/EDGE B2/B3/B5/B8
RF power
2G (GSM): - LB: Class 4(2W, 33dBm ± 2dB)
Class E2(0.5W, 27dBm ± 3dB
@EDGE)
HB: Class 1(1W, 30Bm ± 2dB)
Class E2(0.4W, 26dBm +3/-4 dB
@EDGE)
3G (WCDMA): Class 3(0.25W, 24dBm +1,7/-
3,7 dB)
4G (FDD & TDD): Class 3(0.2W, 23dBm ± 2,7
dB @1RB))
DATA TRANSFER
LTE category 4
LTE FDD: Max 150Mbps (DL)/Max 50Mbps
(UL)
DC-HSPA+ 42 Mbps)
Modulation
E-GSM/DCS: GMSK, 8PSK
UMTS: QPSK
LTE: QPSK, 16 QAM and 64 QAM
2.10.2 BLUETOOTH
Frequency range
2402 ÷ 2480 MHz
RF power
BLE: 8.2 dBm
Modulation
GFSK
CUBE PLUS AP
2.9.3 MODEM PERFORMANCES
BAND
WCDMA B1,B5,B6,B19,B8
FDD B1,B3,B5,B8,B9,B18(B26), B19,B28
RF power
3G (WCDMA): Class 3(0.25W, 24dBm +1,7/-
3,7 dB)
4G (FDD & TDD): Class 3(0.2W, 23dBm ± 2,7
dB @1RB))
DATA TRANSFER
LTE category 4
LTE FDD: Max 150Mbps (DL)/Max 50Mbps
(UL)
DC-HSPA+ 42 Mbps)
Modulation
UMTS: QPSK
LTE: QPSK, 16 QAM and 64 QAM
2.10.3 BLUETOOTH
Frequency range
2402 ÷ 2480 MHz
RF power
BLE: 8.2 dBm
Modulation
GFSK
