Schmidt ADS 250 - Page 41

Copyright © 2020 Axxiom Manufacturing, Inc. 41
Figure 6.4 (a) – Handway Assembly
Figure 6.4 (b) – Handway Components
6” x 8” Handwa
y
Dimensions
Component A B
Weld Rin
g
6-5/8” 8-1/2”
Handwa
y
Cove
r
7-5/8” 9-3/4”
Handwa
y
Gasket 7-3/4” 9-3/4”
SureFit™ Gasket 8-1/16” 10-5/16”
Handwa
y
Cra
b
2-3/8” 8-3/4”
Square Head Bolt 3/4”-10 UNC 4-1/2”
Table 6.4 (c) – Handway Component Dimensions
