WIRING DIAGRAM
66
22
LN
22
Tf
Tp
66
66
230V~50Hz
15
Transformer
Spark Generator
Terminal Block
Microswitch
22 Brown
66 Light Blue
15 Yellow/Green
5413143wd.pdf
PMG41 / PMG42
