INSTALLATION - ELECTRICAL REQUIREMENTS
WARNING - REFER TO THE RATING PLATE FOR VOLTAGE AND CHECK THAT THE
APPLIANCE VOLTAGE CORRESPONDS WITH THE SUPPLY VOLTAGE.
THIS APPLIANCE MUST BE EARTHED. CONNECT TO A 230-240V 50Hz SUPPLY ONLY
When connected to a B.S. 1363 fused plug, a 3 amp fuse must be fitted.
IMPORTANT: The wires in the mains lead fitted to this appliance may not correspond with the coloured
marking identifying the terminals in the plug. if this is the case, proceed as follows: -
The wire which is coloured BLUE must be connected to the terminal which is marked with the N or
coloured BLACK. The wire which is coloured BROWN must be connected to the terminal which is
marked with the letter L or coloured RED.
When wiring the plug, ensure that all strands of wire are securely retained in each terminal. Do not
forget to tighten the mains lead clamp on the plug.
If you are in doubt, consult a qualified electrician.
BLUE - NEUTRAL
BROWN - LIVE
GREEN/YELLOW STRIPES - EARTH
