19
6 Accessories
A wide range of accessories is available
for your KL 1500 LCD. A separate bro-
chure gives you comprehensive infor-
mation – to get it see addresses over-
leaf. Only SCHOTT light guides and
accessories guarantee perfect operati-
on, safety and optimum light yield.
6.1 Light guides
Self-supporting and flexible light gui-
des in various lengths and diameters
are available, as well as point and slit
illuminators.
6.2 Halogen lamps
When ordering halogen lamps as spare
parts (see point 6.4 of this instruction),
the lamp type that enables optimum
light yield and illumination will be sup-
plied.
7 Technical data
Properties Values
General information
Type description - KL 1500 LCD
Dimensions (W x D x H) mm approx. 200 x 265 x 170
Weight kg approx. 5
Cooling - axial
(
fan cooled)
Ambient temperature* °C + 5 ... + 40
Relative air humidity* % at 31°C ambient temperature: 85 %
from 31°C to 40°C ambient temperature:
decreasing linearly to 75 %
Air pressure* hPa 700 ... 1060
Transport and storage
Temperature °C - 40 ... + 70
Rel. air humidity % 10 ... 95 (non-condensing)
Air pressure hPa 500 ... 1200
Contamination level -2
* Test conditions of Standards DIN EN 61010-1, DIN EN 60601-1 and UL 3101-1.
continued on page 20
6.4 Spare parts
Spare part Catalogue No.
Halogen lamp 15 V/150 W 153 000
Philips, type 6423
Philips, type 6423 XHP
Osram, type HLX 64634
Fuse for 230 V (primary) 150 101
T 2 H, 250V acc. to IEC 127-3/5
Fuse for 120 V (primary) 153 103
T 4 A acc. to UL 198 G
6.3 Filters
Optical filters can either be inserted
into the filter slide (7) or placed in
front of the light guide exit as a screw-
in or push-on filter in conjunction with
an auxiliary focussing device
(accessory).
Details of the auxiliary focussing device
and the filter types available as stan-
dard can be found in the accessories
catalogue.
To ensure maximum performance, light yield and safety you must only use the
spare parts stated above.
