PARTS LIST
300AC-220/3 460/3
M.R.I. UNIT
If this unit has special feature(s) installed, see appendix for part number(s).
Refrigeration
Description
Qty.
R106 Compressor – 460/3 – 3 HP 1
R122 Condenser – Air Cooled 1
R131
Receiver – 1 – 3 Ton
1
R140-3 Expansion Valve – 3 HW 1
R142-1 Expansion Valve Flange 1 – 5 HW 1
R146-1 Refrigeration Sight Glass 1
R152 Refrigeration Drier – 3/8” 1
R166 Evaporator - SAC-3 1
R180 Suction Line Heat Exchanger 1
R182 High Pressure Switch 1
R183 Low Pressure Switch 1
Electrical
E101
Disconnect – 80 Amp 1
E101-H Disconnect Handle Only 1
E101-S Disconnect Shaft Only 1
E103 Contactors – 30 Amps 2
E104 4 Point Terminal Block 1
E110-12 Terminal Block – 12 Point 2
E113 Transformer – 440/3 1
E115 Grounding Screw 1
E122 Off/On Switch 2
E124-3 Pilot Light/Bulb – 24V 2
E126 Pilot Light Assembly All Units - Green Lens 2
E128A1 Single Stage w /LLVL & RA 1
E128P-D Discharge Probe Wire 7 ft
E128P-R Return Probe Wire 8 ft
E129 Low Ambient Controls 1
CA128-RB Remote Control Box 1
E132
Thermostat – High Temperature
1
E134 Dial Thermometer – Solid State Controller 1
E138 Low Pressure Water Control 1
E136 Water Pressure Gauge 1
E145 Fan Motor – ½ HP 3 PH Mtr –1140 RPM 60 HZ 1
E148 Fan Blade – 18” - 24 Pitch 1
E153-20 Fan Guard for 18” Blade 1
K08.14
Interlock Loop Kit 1
K09.4F
150’ Control Wires – Marconi Med. 1
Plumbing
P124-S Stainless Steel Tank - 2 HP 1
To Next Page
