Commissioning instructions – Schüco DCS Touch Display 13
Dok-Nr.10000432116_01
4. Technical data
4.1. Schüco DCS Touch Display
General data
Installation type
Integrated in the prole in the DCS unit, leaf and outer frame,
wall mounting and panel mounting
Material Aluminium, PVC-U, toughened safety glass
Colour Black
Weight 0,702 kg
Power supply PoE+ IEE802.3at/Typ2 min 44 V
Alternative power supply IEE802.3at
Input current (max.) 0,5 A
Call, speak, listen functions
Audio coding G.722 , G.711 a-law, G.711 u-law
Video coding H.264
Device data: Screen
Screen TFT active matrix, fully bonded
Size 4,3“
Resolution 480 x 800 Pixel
Screen brightness Min. 450 cd/m², typically 600 cd/m², automatic
Angle of vision 80° in all directions
Colour depth 24 bit (true color)
Contrast ratio 1000 (typical); 700 (minimum)
Device data: Camera
Camera opening angle 120° horizontally, 60° vertically
Video resolution 1280 x 960 (1.2 MP)
Front glass TSG
Light sensitivity Lens: f/2.0
Capability in backlit situations HDR-based compensation
