Schücode Commissioning instructions – Schüco DCS Touch Display
14
Dok-Nr.10000432116_01
Access control
Code lock 4 or 6-digit code entry
System features
Peer-to-Peer operation Yes
Ports Line out, line in, 2 x USB, Ethernet
Inputs 1 input
Outputs 1 potential-free output, can be freely congured
Commissioning and maintenance properties
Conguration
Basic settings on the DCS Touch Display, further settings
via the web interface
Dimensions
Housing 212 x 70 x 46 mm (H x W x D)
Climatic properties
Permissible ambient temperature -20 °C to +70 °C
Protection rating IP 54 (when installed)
Guidelines
Conforms to RoHS, tested in accordance with
IEC/EN 60950-1
