Commissioning instructions – Schüco DCS Touch Display 15
Dok-Nr.10000432116_01
4.2. Schüco IP secure connector
General
Dimensions 262 x 59 x 26 mm (H x W x D)
Protection rating IP 20
Temperature range +5°C to +45°C
Air humidity 5% to 93%, non-condensing
Installation
Integrated in the DCS door prole or by the customer on the
inside of the building
Key electrical data
Power supply
12 - 30 V DC (+/-15 %) stabilised ,
von SELV/LPS (max 100 W) Spannungsquelle
Operating voltage Recommended: 24 V DC, stabilised
DC OUT 3 With potential, 12-30 V DC, max. 1.5 A
OUT 1 / OUT 2 Potential-free
Contact loading of outputs OUT 1
and OUT 2
6-24 V AC/DC + - 15 %, max. 2 A
von SELV/LPS (max 100 W) -Stromkreis
Guidelines
Conforms to CE and RoHS,
IEC/EN 60950-1
INFORMATION
SELV electrical circuit
The relay output must only be used for SELV electrical circuits. A SELV electrical circuit in accordance
with IEC/EN 60950-1 must be securely isolated (e.g. by means of double insulation) from
a dangerous electrical circuit (e.g. 230 V or 110 V mains supply circuit) and must not exceed the
voltage value of 60 V DC or 42.4 V ACpeak (30 V ACeff).
IP secure connector circuit breakers
All inputs and outputs of the IP secure connector are protected against voltages up to 60 V DC and
42 V AC. The „DC-OUT 3“ output also has circuit breakers to protect against external supply, short
circuiting and reverse polarity.
You can nd examples of connecting LED spotlights and/or motion detectors in Chapter 10,
„Connection examples“, in the installation instructions. .
