Schulz BENCH GRINDER 6” - Technical Features; Main Components and Their Functions

31
6. CARACTERÍSTICAS TÉCNICAS
TABLE 6.1 TECHNICAL FEATURES
* Hobby/Home Product
1. Eye shield support – Allows fastening of the eye shield.
2. Eye shield - Retains the metal particles during work.
3. Adjustable tool rest - Allows approach adjustment of the rest, as the grinding wheel wears.
4. On/Off switch – Turns the product on or off.
5. Grinding wheel guard - Protects the user from accidental contact with the grinding wheel.
6. 2P + T Plug – Used to connect the product to the electrical energy supply.
7. MAIN COMPONENTS AND THEIR FUNCTIONS
1
3
2
4
5
MODEL
ABSORBED
POWER
(W)
SPEED
RPM
SINGLE-PHASE ELECTRIC MOTOR
A
L C
DIMENSIONS (MM)
WEIGHT
WITH
MOTOR (kg)
VOLTAGE (V) CURRENT (A) A C L
BENCH GRINDER 6” * 300 3450
127 3,0
270 350 230 7,6
220 1,5
