What to do if the proximity switch moves independently in SCHUNK Measuring Instruments?
If the proximity switch moves independently on your SCHUNK Measuring Instruments, tighten the bracket according to the specified tightening torque. Also, check the protective cover for damage and ensure there is no collision contact to the proximity switch. If required, replace the proximity switch type IN.
Why do I have no control of switching valves due to missing signal output in my SCHUNK Measuring Instruments?
If you have no control of switching valves due to a missing signal output in your SCHUNK Measuring Instruments, it may be caused by a position measuring system that isn't working properly. Check all screw connections of the sensor and the target mounting to ensure they are correctly seated. For an adjustable target, adjust the gap distance of the position measuring system. You may also need to teach in switching windows of the electronic position measuring system using a teaching device and program them in. Another possible cause is that the position measuring system is not reporting any signal. Inspect the sensor and feed cable of the position measuring system for any damage and replace them if needed. Alternatively, the proximity switch may not be switching. Readjust the positions and ad...
General| Stroke Z | 138 mm |
|---|---|
| Measuring range Z | 138 mm |
| Resolution | 0.001 mm |
| Accuracy | ±0.02 mm |
| Supply voltage | 24 V DC |
| Protection class | IP40 |
| Repetition accuracy X/Y/Z | 0.01 mm |
| Weight | 4800 g |
| Measuring range | 138 mm (Z), ±25 mm (X/Y) |
| Operating temperature | 0 to 50 °C |
| Storage temperature | -20°C to +70°C |
