OPERATING INSTRUCTIONS AND SAFETY INSTRUCTIONS WI-FI OUTDOOR SOCKET ADAPTER
Schwaiger GmbH
Würzburger Straße 17 | 90579 Langenzenn
Hotline: +49 (0) 9101 702-299
www.schwaiger.de | info@schwaiger.de
SOAW0044
SOAW0044_BDA
GENERAL
Read the user guide and keep it in a safe place.
Congratulations and thank you for purchasing this Schwaiger Product.
This user manual is an integral part of this product. It contains important
information on commissioning and handling.
This user manual is intended to assist you in using the product. Read
through the instructions for use carefully. Store this guide safely through-
out the product’s entire service life and pass it on to any subsequent
users or owners. Check that the supplied package is complete and ensure
that none of the parts are defective or damaged.
INTENDED USE
The product is intended for private use only and is not suitable for com-
mercial use. Only use the product as described in this user manual. Any
other use is considered improper and may result in property damage.
WARNING!
Hazards for children and persons with reduced physical, sensory
or mental abilities (for example, partially disabled persons, elder-
ly persons with reduced physical and mental abilities) or lack of
experience and knowledge (for example, older children).
This product can be used by children aged from eight years and above
and persons with reduced physical, sensory, or mental capabilities or lack
of experience and knowledge if they have been given supervision or in-
struction concerning use of the product in a safe way and understand the
hazards involved. Children must not play with the product. Cleaning and
user maintenance must not be carried out by children without supervi-
sion.
• Keep children younger than eight years away from the product and the
connecting cable.
• Do not leave the product unattended during operation.
• Do not allow children to play with the packaging film. Children can get
caught in it while playing and suffocate.
GENERAL SAFETY AND WARNING INSTRUCTIONS
WARNUNG!
Risk of electric shock!
Faulty electrical installation or excessive mains voltage can lead to elec-
tric shock.
• Do not operate the product if it shows visible damage or if the power
cord is defective.
• Always check the product for damage before use. Damaged electrical
equipment as well as kinked power cords or bare wires increase the
risk of electric shock.
• Do not open the housing but entrust the repair to specialists. Contact a
specialist workshop for this purpose. Liability and warranty claims are
excluded in the event of repairs carried out independently, improper
connection or incorrect operation.
• Do not disassemble the product into its individual parts. Improper han-
dling can lead to electric shock and malfunction.
• The mains plug of the device must fit into the socket. The power plug
is not allowed to be modified in any way. Do not use adapter plugs
together with protective grounded electrical equipment. Unmodified
power plugs and matching outlets reduce the risk of electric shock.
• Only parts that correspond to the original device data may be used for
repairs. This product contains electrical and mechanical parts which are
essential for protection against sources of danger.
• Never immerse the product in water.
• Keep the product away from open flames and hot surfaces.
• Never operate the product in wet areas or in the rain.
• Do not expose the product to rain or extreme weather conditions e.g.,
sub-zero temperatures, hail, extreme heat.
• Never place the product in such a way that it can fall into water.
• Make sure that no liquid gets into the product and, if necessary, dry the
product thoroughly before using it again.
• Ensure that children do not insert any objects into the product.
• Keep the product at least 20 cm away from pacemakers and other
medical devices. Radio waves can affect the function of pacemakers
and other medical devices.
• When you are not using the product, cleaning it or if a malfunction
occurs, always switch off the product and disconnect the power plug.
• If there are large fluctuations in temperature or humidity, condensation
may cause moisture to form inside the product, which may cause an
electrical short circuit. After transporting the product, wait until it has
reached ambient temperature before putting it into operation.
• The prerequisite for proper functioning of the product is a functioning
protective conductor connection of the wall socket (protective contact
socket) at which the product is operated.
• Despite the high energy dissipation capacity, there is no absolute safe-
ty of the connected devices in case of direct lightning strike.
WARNUNG!
Explosion hazard!
Do not operate the device in an explosive environment containing flam-
mable liquids or gases. Never exceed the specified maximum input volt-
age.
• Avoid strong vibrations.
• Do not expose the product to rain or extreme weather conditions, e.g.
minus temperatures, hail, extreme heat.
• Do not expose the device to extreme temperature fluctuations. Do not
put it into use until it has adjusted to the ambient temperature.
• Only use a wall socket that is easily accessible. This way, the mains
plug can be pulled out quickly in emergencies.
• Never operate the power strip covered.
• Do not connect devices with a total power greater than 3,680 W or a
total current consumption greater than 16 A to the product.
NOTE!
Risk of damage!
Improper handling of the product may result in damage to the product.
• Do not drop the product or expose it to strong vibrations.
• Keep at least 1 m away from high-frequency and magnetic interference
sources (TV set, other speaker boxes, etc.) to avoid malfunctions.
• Never place the product on or near hot surfaces (e.g., stove tops).
• Do not bring the product into contact with hot parts.
• Operate the product only from grounded outlets rated 100 - 240 V AC,
50/60 Hz. If you are unsure of the power supply at the installation site,
check with the relevant power supplier.
• Do not operate the device at too high mains voltage, with a universal
socket or any other connecting device. Operate only at input voltage
specified on type plate.
• Unplug the product during lightning storms or when unused for long
periods of time.
• Never expose the product to high temperature (heating, etc.) or
weather (rain, etc.).
• Never pour liquid into the product.
• Never immerse the product in water for cleaning and do not use a
steam cleaner for cleaning. The product may otherwise be damaged.
• Do not use the product if the plastic components of the product are
cracked or deformed. Replace damaged components only with suitable
original spare parts.
OPERATION IN DETAIL
Check product and scope of delivery
Package contents
• 1x WiFi socket outdoor
• this instruction manual
Risk of damage!
If you open the packaging carelessly with a sharp knife or other pointed
objects, the product can be damaged quickly.
1. Be very careful when opening it.
2. Remove the product from the packaging.
3. Check if the delivery is complete.
4. Check whether the product or the individual parts show any damage.
If this is the case, do not use the product. Contact the hotline or
e-mail address specified in this instruction manual.
Connection and commissioning
• Only operate the product from an approved socket.
• Disconnect the product from the mains if you are not going to use it
for a long time.
• Do not operate any heat-generating devices (e.g. electric blankets, cof-
fee machines, etc.) with this product. There is a risk of fire and injury!
• Connect the WiFi socket to a properly installed and easily accessible
mains socket.
• Press and hold the button on the socket for approx. 5 seconds until the
LED starts to flash quickly.
Connect
• Download the APP Smart Life from the Apple App
Store or on Google Play.
• Open the respective APP.
• As a first-time user, you must register and create a
new account. If you already have an account, log in
with your access data.
FREE DOWNLOAD
AT
or
NOTE!
Make sure that your device (smartphone or tablet) is on the same home
network (Wi-Fi) during setup.
NOTE!
The WiFi socket only works on the 2.4 GHz network!
Check that you are on a 2.4 GHz network.
NOTE!
Installing multiple Wi-Fi sockets
Do not try to use several WiFi sockets at the same time! Each WLAN
socket must be put into operation separately! Do not connect more than
one socket per search.
Pairing the devices in the Smart Life app
• Press and hold the pairing button for approx. 5 seconds. The LED will
start flashing green quickly. If it flashes slowly, press and hold the but-
ton again for about 5 seconds.
• Open the app and log in.
• Press „+“ in the top right corner to add a new device.
• In the list, select power strip, sockets as required.
• Next, enter your WiFi password and confirm with „NEXT“.
• Now confirm that the LED of the socket/plug strip is flashing quickly by
ticking „Next step“ and clicking on „Next“.
• Your socket outlet/power strip will now be connected.
• If the connection is successful, the LED stops flashing quickly and the
app confirms that your sensor has been connected. Now you can give
it your own name.
• Now you can configure the device or set personal scenarios.
Setting options in the Smart Life app
• On/Off
• Timer Function
(unit can be switched on/off at a desired time)
- Countdown (unit is switched on/off after a set time.)
- Schedule
(unit can be switched on and off after any number of set times)
- Circulate
(unit is automatically switched on and then off again
at any set times)
- Inching (unit is automatically switched off after a set
time each time
it is switched on)Electric (app displays the power consumption
exactly to the year / month / day depending on the selection)
• Setting
- Deleting the recorded current data
- Activate / deactivate reminder mode (of the last setting)
- Overcharge switch (automatic switch-off of the unit if the power is
power of < 3 watts over 40min)
- Child lock
NOTE!
You can also use the Electric function to measure how much electricity
you feed into your grid through, for example, a balcony power plant.
TECHNICAL DATA
Model SOAW0044
Input voltage 230 V
50 Hz / 16.0 A
Output voltage 230 V
50 Hz / 16.0 A
Connected load 3.680 Watt
WLAN Standard IEEE 802.1 1 b/g/n
WLAN frequency band 2.4 GHz (2.412 GHz - 2.472 GHz)
WLAN transmission power Max. 20 dBm, 100 mW
Voice control via
Alexa & Google Home
Yes
App name Smart Life
Protection class IP44
MAINTENANCE & CLEANING
IMPORTANT!
Risk of electric shock!
Always unplug the power cord before cleaning the product.
Also disconnect all power plugs of the connected electrical devices from
the product.
Short circuit hazard!
Water or other liquids entering the housing can cause a short circuit.
• Never immerse the product in water or other liquids.
• Make sure that no water or other liquids get into the housing.
Risk of damage!
Improper handling of the product may result in damage to the product.
Do not use aggressive cleaning agents, brushes with metal or nylon bris-
tles, or sharp or metallic cleaning objects such as knives, hard spatulas,
and the like. These can damage the surfaces.
1. Disconnect the power plug before cleaning the product.
2. Before cleaning, switch off the product.
3. Clean the product with a soft, dry cloth.
4. If the product is stubbornly dirty, use a slightly damp cloth and a little
mild detergent if necessary.
5. Allow all parts to dry completely afterwards.
NOTE!
Storage
• All parts must be completely dry before storage
• Always store the product in a dry place.
• Store the product out of reach of children, securely closed and at a
storage temperature between 5 °C and 20 °C (room temperature).
Simplified declaration of conformity as per
the RED Directive
Schwaiger GmbH hereby declares that the described radio system
product complies with Directive 2014/53/EU and other directives applica-
ble to the product. The complete EU declaration of conformity is available
online at:
https://download.schwaiger.de
Disposal
Do not dispose of batteries or electric and electronic devices in the
normal household waste. The consumer is legally obliged to return
electrical and electronic devices and batteries that are at the end of
their useful life to the point of sale or public collection points that have
been set up for this purpose. Legislation in the country of use governs
individual details regarding disposal. The symbol on the product, the user
guide or the packaging indicates this legal requirement.
Disclaimer
Schwaiger GmbH does not accept any liability or warranty for damages
that are sustained due to improper installation or mounting, improper use
of the product or non-compliance with the safety instructions.
Warranty
The warranty period starts when the product is purchased. The purchase
receipt, such as a till receipt, invoice or delivery slip, serves as proof of
this date. Keep these documents in a safe place. Our warranty is based
on our warranty conditions valid at the time of purchase.
Manufacturer‘s information
Dear Customer, please contact our Technical Support if you need technical
advice and your retailer is unable to help you.
Office Hours
(Technical Support in German)
Monday to Friday: 8:00 a.m. - 5:00 p.m.
To Previous Page
Loading...
