Date Code 20020215 Serial Port Communications and Commands 10-35
SEL-351R Instruction Manual
If the relay is an SEL-351R-2, this command also displays NLB9–NLB16, CLB9–CLB16,
SLB9–SLB16, PLB9–PLB16, DP9_1–DP16_1, and DP9_0–DP16_0.
=>>SHO T <ENTER>
Text Labels:
NLB1 = CLB1 = SLB1 = PLB1 =
NLB2 = CLB2 = SLB2 = PLB2 =
NLB3 = CLB3 = SLB3 = PLB3 =
NLB4 = CLB4 = SLB4 = PLB4 =
NLB5 = CLB5 = SLB5 = PLB5 =
NLB6 = CLB6 = SLB6 = PLB6 =
NLB7 = CLB7 = SLB7 = PLB7 =
NLB8 = CLB8 = SLB8 = PLB8 =
DP1_1 = DP1_0 =
DP2_1 = DP2_0 =
DP3_1 = DP3_0 =
DP4_1 = DP4_0 =
DP5_1 = DP5_0 =
DP6_1 = DP6_0 =
DP7_1 = DP7_0 =
DP8_1 = DP8_0 =
79LL =SET RECLOSURES 79SL =RECLOSE COUNT
=>>
STA Command (Recloser Control Self-Test Status)
The STA command displays the status report, showing the recloser control self-test information.
To view a status report, enter the command:
=>STA n <ENTER>
where n is an optional parameter to specify the number of times (1–32767) to repeat the status
display. If n is not specified, the status report is displayed once. A typical SEL-351R status
report output appears as shown below:
=>STA <ENTER>
RECLOSER R1 Date: 02/01/98 Time: 12:21:48.226
FEEDER 2101
FID=SEL-351R-R101-Vf-D980415 CID=0A59 BCBFID=R100
SELF TESTS
W=Warn F=Fail
IA IB IC IN VA VB VC VS MOF
OS -0 -0 -0 -0 -1 0 -0 -0 -0
+5V_PS +5V_REG -5V_REG +12V_PS -12V_PS +15V_PS -15V_PS
PS 5.06 5.03 -4.98 11.97 -12.01 15.07 -15.12
TEMP RAM ROM A/D CR_RAM EEPROM IO_BRD
39.5 OK OK OK OK OK OK
MODE %CAP HRS_LFT 5V_PSBC 12V_AUX VBAT IBAT
BATT CHARGE 93 XX:XX 5.02 0.00 30.59 14
Relay Enabled
Battery Charger Board Enabled
=>
