Item Qty Description Item Qty Description
1 1 Console Assembly 10 1 Heart Rate Chest Strap
2 1 Console Backing 11 1 Upright, Left
3 1 Upright, Right 12 1
Handlebar Shroud, Lower Left
4 1
Handlebar Shroud, Upper Right
13 1
Handlebar Shroud, Upper Left
5 1
Handlebar Shroud, Lower Right
14 1 Tray, Left
6 1 Base Shroud, Right 15 1 Tray, Right
7 1
Base Assembly (
* )
16 1 Safety Key
8 1 Base Shroud, Left 17 1
Media Cable (not shown)
9 1 Power Cord 18 1 Silicone Lubricant, Bottle (not shown)
DO NOT CUT the Shipping Strap on the Base Assembly until it has been placed face up as shown in
the appropriate work space ( * ).
PARTS
1
14
10
9
15
4
5
6
3
7
8
12
13
11
2
16
*
