Schwinn CV309 - Attach the Front Wheel

6
ATTACH THE FRONT WHEEL
 Loosen the locking nut by hand. 
 Align wheel axle with front wheel forks and insert wheel. Figure
Finger ghten the locking nut located on one side of the axle.
 Lock axle in place by pressing the quick release lever toward the
wheel , unl it is secured against the frame.
NOTE: It may be dicult to press the quick release lever against
the frame. If so, release the lever, loosen locking nut one or two
turns and try again.
 


  Pull quick release lever away from wheel.


Quick
Release
Lever
Quick
Release
Lever
Locking
Nut
2
1
3
Fork Fork
