Front Derailleur
(Fig. 3.44) Shi both shiers to the smallest number indicated and place the chain
on the corresponding cog and chainwheel. Disconnect the front derailleur cable from
the cable anchor bolt. Check the posion of the front derailleur; it should be parallel
with the outer chainwheel and clear the largest chainwheel by 1-3mm when fully
engaged. With the chain on the smallest chainwheel in front and the largest cog in back,
adjust the Low limit screw so the chain is centered in the front derailleur cage. Reconnect
the cable, pull any slack out, and ghten the anchor bolt securely. Shi the front shier
to the largest chainwheel. If the chain does not go onto the largest chainwheel, turn the
high limit screw in 1/4 turn increments counter-clockwise unl the chain engages the
largest chainwheel. If the chain falls o the largest chainwheel, and into the pedals, you
will need to turn the High limit screw in 1/4 turn increments clockwise unl the chain
no longer falls o. Shi through every gear, using the barrel adjusters to ne tune each
transion. The barrel adjuster for the front derailleur is located on the front shier where
the cable comes out of the shier. Clockwise will loosen the cable tension and direct the
chain closer to the frame while counter-clockwise will ghten the cable tension and
direct the chain away from the frame.
Do not ride a bicycle that is not shiing properly. Overlooking proper
adjustments may cause irreparable damage to the bicycle and/or bodily
injury. Never move the shier while pedaling standing up, or under heavy
load, nor pedal backwards aer having moved the shier. This could jam
the chain and cause serious damage to the bicycle and/or rider.
