FRONT BRAKE
CAUTION: Improper use of the front brake may cause front wheel to lock up
resulng in loss of direconal control or front pitch over.
Determine which type of brake your bike is equipped with and refer to the appropriate
assembly instrucons below. *Addionally some freestyle models may be equipped
with a “cable detangler”. See assembly steps for cable detangler.
Caliper Brake
If the brake cable is not connected at the brake lever, slide the head of the brake cable
into the brake lever per the diagram, and thread the cable through the slot in the brake
lever so the cable end rests squarely in the adjustment barrel or cable end rests in the
recess of the brake lever. (Fig. 3.16)
Brake adjustment
If the brake cable is disconnected at the caliper, thread the brake wire through the
adjustment barrel, loosen the cable anchor bolt unl you can see a hole through the
anchor bolt for the cable wire to aach, thread the cable wire through the cable anchor
and snug the cable anchor by hand. (Fig. 3.17)
Check to be sure the cable is seated in the brake lever. Loosen the cable anchor bolt
just enough to allow the cable wire to move freely. With your le hand squeeze the
caliper brake unl both brake pads contact the rim. While holding the brake closed
with your le hand, use your right hand to pull the brake cable ght (through the
cable anchor) again inspecng that the cable end is seated in the brake lever, and
the barrel adjuster of the brake. Tighten the cable anchor as much as you can by
hand, and then while sll squeezing the brake, ghten the cable anchor fully with
a wrench. (Fig. 3.18)
