Schwinn MPower Echelon2 - Service Menu Operations; Accessing and Navigating the Service Menu

Page 18
Page 19
In the Service menu, the following actions can be performed:
• The following system settings can be changed:
- CARBON BLUE
1
: ON/OFF
- UNITS: MI/KM
- GEAR: ON/OFF
- OPEN ANT: ON/OFF
2
- BACKLIGHT: Multiple options
- CALORIES: ON/OFF
- PASSCODE: ON/OFF
- SENSOR TYPE: 4 IIII/Echelon2
• Power sensor can be calibrated
• Power levels can be adjusted up or down
• External battery level can be checked
• New rmware can be loaded
• Console ID can be checked or changed
• Console can be reset
NOTE: Only club maintenance sta and other club sta that are properly trained on how to
navigate the Service menu, change settings, and calibrate the sensor should ever be allowed
to enter the Service Menu and make any changes.
Detailed instructions on changing settings and performing actions in the Service menu appear
below.
To access and navigate the Service menu:
1. The console must be in either power up mode (just after power up and before pedaling) or Pause mode in
order to enter the service menu.
2. In power up or Pause mode, press and hold the and AVG/MAX buttons together for 3 to 5 seconds.
3. If the passcode is set, enter the passcode to access. The passcode is a 3-digit number assigned by Schwinn and
cannot be changed. Contact Schwinn support to obtain the passcode. To enter the passcode, use the
or AVG/MAX buttons to scroll to the desired number, then press the button to accept the number and
advance to the next number. After the third number has been entered the service menu will open.
4. The rst menu option that will appear is CARBON BLUE. See the diagram below for all top-level menus options.
5. To scroll through the menus, use the AVG/MAX button to scroll forward and the button to scroll back-
wards.
6. To select a menu option press the button to enter the menu. For system settings, use the AVG/MAX or
buttons to select the desired option and exit the menu. Diagrams for each menu are illustrated below.
7. To exit the Service menu, get to the top menu level, scroll to EXIT and press the button.
1 Does not aect power calculations on Schwinn Power bikes.
2 Must be turned on when console is used to broadcast to an external leaderboard system.
SERVICE MENU
