Page 9
Buttons and Features Description Function
1 Power
• Rider’s instantaneous power measured in
watts.
2 RPM
• Rider’s instantaneous RPM (a.k.a. cadence), or
rotations per minute of the crank arm.
3 Heart Rate
• Rider’s heart rate in beats per minute (BPM)
when paired with a compatible heart rate
monitor.
4 Calories
• Optional Calorie display that can be turned
o in Service menu.
• Based only on power and not estimated from
heart rate.
5 Gear Display
• Optional “Gear” or level of resistance the rider
is riding at—can be turned o in the Service
menu.
6 Battery Level Indicator
• Battery level that is shown for 30 seconds
when the console is rst powered on.
7 Stage Timer
• Stage timer that is activated with the STAGE
button.
8 Stage distance
• Distance traveled in a stage in miles or kilo-
meters (set in Service menu).
9 Stage AVG/MAX Power
• Average power for the stage only —MAX
power can be seen by pressing the AVG/MAX
button twice.
10 Total Ride Timer
• Timer starts timing the ride as soon as the
rider begins pedaling, and will continue timing
until console enters SUMMARY mode.
11 Total Ride Distance
• Distance traveled in in the ride in miles or
kilometers (set in Service menu).
12 Total Ride Average Power
• Average power for the ride —MAX power
can be seen by pressing the AVG/MAX button
twice.
