Schwinn MPower - Battery Status Details; Numeric Battery Level Display; Battery Level Icon Guide

32 pages

To Next Page

To Previous Page

A12

ErrorMessage(Current/Last)

A24DeviceID

A13

Current(Sub)MenuOption

A25DeviceName

A14MenuNumberIndicatorA26NumericLevel

A22

TotalOperationTime(ifapplicable)

BatteryLevelicon

A23

CurrentVoltageLevel(ifapplicable)

TotalOperationTime:ForSpeedSensorandPowerSensoronly.

CurrentVoltageLevel:ForConsoleandPowerSensoronly.

DeviceName:

Typeofdevice—“Batt”(system),“CONSL”(console),“P:SenS”(powersensor),

“SPEEd”(speedsensor).

NumericLevel:

TheLCDshowsavalueof00.0–99.9(lowtohigh)asapercentageofbatterylife.

BatteryLevelicon:

All4segmentsoftheiconareonwhenthebatterylevelishigh.Whenthe

batterylevelislow,onlythebottomsegmentisonandtheiconflashes.

Whenyouselectthesubmenuoptionforaspecificbattery(AP1,AP2orAP3),theconsoleshowsthelevelofthatbattery:

19 19

AP-:
