Schwinn MPower - Console Status and Maintenance Options; Battery Status Icon Correlation; Console Status Menu Options

BatteryStatus
Icon
ConsoleSpeed
Sensor
PowerSensorVoltage
4segments
80–100%80–100%
1.5Vormore
3segments
60–80%60–80%
1.3–1.499V
2segments
40–60%40–60%
1.1–1.299V
1segment
20–40%20–40%
0.9–1.099V
1segmentflashing
lessthan20%lessthan20%
lessthan0.9V
Ifthebatterylevelislow,refertotheinstructionsforbatteryreplacementinthismanual.
ConsoleStatus
TheEPoptionintheServiceModemenuletsyouinspectmaintenancedataintheconsoleandadjustsettingsintheEEPROM
firmwarethroughthesubmenuoptions:
• •
•
EP0—Consolesetupsummary
• •
•
EP1—Console“Reset”functionfortechniciantoupdatethefirmware.
• •
•
EP2—Activespeedoptionletsyouchangethe80RPMthreshold(defaultvalue)fortheconsoletostartWorkoutMode.
• •
•
EPN—CumulativeworkoutstatisticsforRPMandPower
• •
•
EPE—EraseEEPROMtosetconsolebacktodefaultsanderasedevicepairing.
• •
•
EPr—Errorhistory
• •
•
EPb—Backlightoptions
• •
•
“––”—Exit
EP0:
