17
38 brkt., pivot, rod, lock A1119 1
39 spring 1
40 frame, seat 71385 2
41 lockwasher, 1/4, blk. 4
42 seat pad (back) 71101 1
43 seat pad (bottom) 71100 1
44 lockwasher, 1/4, pltd. P1056 4
45 bolt, 1/4-20x1.25, pltd. 4
46 bracket, spring A1120 1
47 sticker, track adjustment 1
48 track, adjustment, seat, stainless steel, Pro1000 A1114 1
49 decal, manufacturing date 1
50 endcap, 3"dia 70330 2
51 screw, M5x1.0x25, s.h., blk. 16
52 manual, operator's 1
53 cord, power, 110V, 9'10" 65169 1
54 frame, main 69321 1
55 screw, 10-32x.75, s.h., blk. 3
56 lockwasher, #10, pltd. 3
57 shaft, brake, drive, pulley 68312-2 1
58 bolt, M5x.8x19, socket cap 3
59 ring, snap, retainer, 1/2 1
60 bearing, hub, brake drive 68012 2
61 lockwasher, #8, pltd. 11
62 hub, brake drive pulley, hubed 68316-2 1
63 pulley, brake drive 68313 1
64 freewheel, Pro II, shimano 68013 4
65 0.020" and 0.035" shims NA
66 tape, pickup, speed 65141 1
67 bolt, 8-36x1.188, blk. 1
68 brake, assy. 68000 1
69 belt, brake, poly-v 68014 1
70 channel, transformer A1359 1
71 screws, 4-40x.5 p.h. pltd. 1
72 washer, #4, split, pltd. 1
73 washer, #4, flat, pltd. 1
74 sensor, speed, assy. 65140 1
75 transformer, 24V, 5.4 A 65180 1
76 bracket, speed sensor 69403 1
77 screw, M4x.7x10, s.h., blk. 4
78 washer, M4, pltd. 4
