OVERVIEW
Low engine oil pressure warning
1
Driver seat belt reminder
1
(alarm will sound if speed is over 12 mph)
Front passenger seat belt reminder
1
(alarm will sound if speed is over 12 mph)
Brake system warning
1
Charging system warning
1
Malfunction/Check Engine indicator
1
Indicator symbols
Instrument cluster
Service indicator and reminder
Speedometer
MODE switch
Multi-information display
Tachometer
Shift position indicator
Fuel gauge
1
For details, refer to “Service reminder indicators and warning buzzers,” Section 1-6,
2011 Owner’s Manual.
2
For details, refer to “Engine coolant temperature indicator and warning light,”
Section 1-6, 2011 Owner’s Manual.
3
If t
Open door warning
1
Airbag SRS warning
1
