OVERVIEW
Instrument cluster
Speedometer
Dashboard Illumination
Odometer, Trip Meter and Trip, Meter Selector
Fuel Gauge
Outside Temperature Display
Tachometer*
Indicators and warning lights
*
If equipped
High Engine Coolant Temperature Warning [Red]
1
Master Warning
1
Charging system warning
1
Brake System Warning
1,2
ABS Warning
1
Malfunction/Check Engine indicator
1
Indicator symbols
Power Steering Malfunction Indicator
1
Air Bag/Front Seat Belt Pretensioner System Warning
1
Automatic Transaxle Warning
1,3
For details, refer to “Indicators and warning lights,” Section 3-2, 2016 Owner’s
Manual.
Low engine oil pressure warning
1
Check Fuel Cap Warning
1
Door-Ajar Warning
Seat Belt Warning (Front seat)
Smart City Brake Support (SCBS) Warning [Amber]
Tire Pressure Monitoring System Warning
1
KEY Warning [Red]
1
Low Washer Fluid Level Warning
Low Fuel Warning
Wrench Indicator
1
Low Engine Coolant Temperature Indicator [Blue]
TSC/DSC Indicator
1
DSC OFF Indicator
1
Security Indicator
1
Shift Position Indication
3
Turn Signal/Hazard Warning Indicator
Select Mode Indicator
3
Lights-On Indicator
Front Passenger Air Bag Deactivation Indicator
1
Cruise control indicator
Headlight High-Beam Indicator
1
If indicator does not come on or turn off within a few seconds of starting engine, there may be
a malfunction. Have vehicle inspected by your Scion dealer.
2
The light turns on continuously when the parking brake is applied.
3
If equipped
To Next Page
