Spare tire & tools
Tool and spare tire location
Removing the spare tire
(1) Remove the luggage mat.
(2) Remove the center auxiliary boxes.
(3) Loosen the center fastener that secures the spare tire.
Refer to the Owner’s Manual for jack positioning and tire changing procedures.
rn
ator
to
on
s
in
Spare tire
Jack handle
Jack
Wheel nut wrench
(1)
(2)
(3)
