SCM SC 10 - Page 27

26
A*
B
C
D
DN
Overall Dimensions
SC/L
SC/L
Type
SC 10/L
SC 30/L
SC 55/L
SC 75/L
SC 100/L
SC 120/L
SC 180/L
SC 220/L
SC 300/L
SC 400/L
SC 500/L
SC 800/L
ABCD DN/ø
mm
290
480
480
480
480
625
625
691
691
710
770
770
mm
195
336
336
330
330
330
330
355
355
355
355
355
mm
630
800
890
890
985
985
1060
1075
1075
1290
1300
1300
50/60,3
80/88,9
80/88,9
80/88,9
100/114,3
100/114,3
100/114,3
125/139,7
125/139,7
150/168,3
150/168,3
200/219,1
Weight
Kg
60
144
176
208
243
258
335
398
458
678
790
887
ø mm
750
1460
1460
2245
2245
2450
2450
2860
2860
2860
2950
2950
* Extended channels of different dimensions are available upon request.
