DataPage Lite Desktop UHF Radio Paging System
DPUKLITE 7 Issue 2
1: Setup
Press key 1. The screen changes to:
PAGER BAUD RATE
1:1200 5: 512
To change the transmission baud rate enter 1 for 1200 or 5 for 512
After pressing your selection the screen will change to:
*BASE IDENTITY*
> 0100000
The displayed Base number can be used or you can type in the required number.
After pressing ENTER, the screen will change to confirm the new settings and you are prompted to accept by
pressing ENTER or Cancel. CANCEL will take you back to the *USER OPTIONS * screen.
After pressing ENTER, the screen display will return to the *USER OPTIONS* but with updated settings.
*USER OPTIONS*
1:SETUP 2:RANGE
Press key 2 to select the out of range option
Press any key to toggle between out of range OFF or out of range ACTIVE, then press Enter to confirm.
To return to the pager entry screen press ENTER or CANCEL when at the main programming menu.
The default setting for the out of range cap code is THE BASE ID, the beep type is A, the TX baud rate is 1200
NOTE! This feature is only available using 1200 baud.
Problems and Fault Finding
Check that there is power at the mains socket.
Check that the pagers are at least 3 meters from the transmitter and aerial. Under certain conditions it is
possible to flood the pager receivers and corrupt the data received.
Check that the pagers have the battery installed with the correct polarity and are correctly powered up.
Check that the aerial is correctly installed.
Check the Base ID on the password menu matches the system data. Check the transmission baud rate
matches the system data.
