2002-05 LINCOLN AVIATOR
RADIO REMOVAL:
1. Using a panel removal tool, unsnap and remove vent panel above radio at the top of the dash.
2. Extract (2) 7mm screws that are now exposed under panel.
3. Using a panel removal tool, unsnap bezel surrounding the radio and remove.
4. Using a panel removal tool, unsnap and remove vents below radio.
4. Extract (4) 7mm screws from radio mounting. Unplug and remove.
2001-04 FORD MUSTANG
RADIO REMOVAL:
1. Use a panel removal tool to pry out gear shifter bezel.
2. Use a panel removal tool to pry out radio trim bezel.
3. Extract (2) 9/32" screws, located below the stereo,
disconnect and remove.
2003-06 LINCOLN NAVIGATOR
RADIO REMOVAL:
1. Open the center console door and remove (1) push-pin type fastener from power window switch
panel. Unsnap, unplug and remove panel.
2. Extract (2) 7mm hex screws from back of gear shift/cup holder panel, unsnap and lift panel out
of the way.
3. Extract (2) 7mm hex screws from below ashtray.
4. Use a panel removal tool to carefully unsnap and remove the entire radio-A/C control center
dash bezel, unplug and remove.
5. Extract (2) 7mm hex screws from below stereo, unplug and remove stereo.
2007-09 LINCOLN NAVIGATOR W/ NAV
RADIO REMOVAL:
1. Using a panel removal tool, unsnap shifter trim bezel around shifter.
2. Remove (2) 7mm screws at bottom of panel
3. Using a panel removal tool, unsnap radio trim panel unplug harness and remove.
2005-09 FORD MUSTANG
RADIO REMOVAL:
1. Open center console, remove (2) Phillips head screws from back of console cover. Lift up and
remove (Console cover is held in place by (2) screws in back, press clips on each side
and front).
2. Remove panel from along-side of center dash by pulling from bottom to top. Panels are held in
place via press clips.
3. To remove radio trim bezel, extract (6) 7mm screws (three on each side) from panel. Unplug heat
and A/C control harnesses, remove panel. Extract (4) 7mm screws from radio mounting. Unplug
and remove.
2007-09 LINCOLN MKX
RADIO REMOVAL:
1. Open center console Lid, and using a panel removal tool, unsnap bezel surrounding shifter and
remove.
2. Extract (2) Phillips head screws below pocket and remove.
3. Using a panel removal tool, unsnap bezel surrounding the radio and remove.
4. Extract (4) 7mm screws from radio mounting. Unplug and remove.
