Scotsman MV 600 - Page 22

The installation of the
metal plate (air
separator) grants also a
minimum distance
between the back side of
the machine and the wall
so to assure a correct and
adequate ventilation.
TOP VIEW
MINIMUM
MINIMUM
DISTANCE
DISTANCE
INSTALLATION
INSTALLATION
MV 300-450-600-1000
MV 300-450-600-1000
