Scotsman Prodigy Plus A Series - NH0422, NS0422, FS0522, NH0622, NS0622, F0822 Cabinet Layout

NH0422, NS0422, FS0522, NH0622, NS0622, FS0822, NH0922, NS0922, FS1222, NH1322, NS1322, FS1522
A Series Air, Water, or Remote User Manual
October 2019
Page 4
NH0422, NS0422, FS0522, NH0622, NS0622, F0822 Cabinet Layout
ICE DROP OPENING
REMOTE COOLED
BACK VIEW
WATER COOLED
BACK VIEW
AIR COOLED
BACK VIEW
LEFT SIDE VIEW
FRONT VIEW
57.7
22.70
58.4
23.00
55.9
22.00
LOUVER AND REMOVABLE FILTER
A/C UNITS ONLY
61
24.00
2.3 .90
4
1.59
5.5
2.17
4.7
1.85
23.1
9.1
37.2
14.65
3/4" FPT DRAIN
.88 DIA. ELECTRICAL ACCESS
3/8" FLARE MACHINE WATER INLET
61
24.00
REF.
41.9
16.50
31.8
12.50
55.9
22.00 REF.
10.9 4.30
16.5 6.48
7.1
2.81
7.4
2.92
PLAN VIEW
23.1
9.1
4
1.59
5.5
2.17
4.7
1.85
37.1
14.60
8.6
3.38
39.2
15.45
44.6
17.55
49.1
19.31
3/8" FPT CONDENSER WATER INLET
.88 DIA. ELECTRICAL CONNECTION
3/8" FLARE MACHINE WATER INLET
3/4" FPT DRAIN
1/2" FPT CONDENSER DRAIN
23.1
9.1
4.7
1.85
37.1
14.60
4
1.59
5.5
2.17
17.2 6.78
23.6 9.28
48.9
19.24
REMOTE COND. LIQUID LINE 3/8" COPPER BRAZE JOINT.
REMOTE COND. DISCHARGE LINE 1/2" COPPER BRAZE JOINT
.88 DIA. ELECTRICAL CONNECTION
3/4" FPT DRAIN
3/8" FLARE MACHINE WATER INLET
Note: Bin Top Cut-outs for drop zone should include ultrasonic sensor location
