ENGLISH
33 |
ROAD BIKE | OWNER’S MANUAL 2021
You will feel an increasing resistance at the lever. Only turn the axle until it is
hand-tight.
Make sure the RWS quick-release lever does not stand out to the front (d).
Open the RWS quick-release lever a little (e, position 1) to bring it into a favour-
able position. Turn the RWS quick-release lever then into the desired position (e,
position 2) and re-close it towards the hub (e, position 3).
Actuate the brake lever to make the brake work. Lift the wheel and give it a
strong tap from above. The wheel must be securely fixed and must not rattle.
Wheel removal
Turn the quick-release lever anticlockwise to open the RWS system. Release the
thru axle completely by two and a half turns, hold the wheel in its position and
remove the axle from the hub.
WARNING
Improperly mounted wheels may throw you off your bike or result in serious
accidents! Therefore, if you have the slightest doubt, contact your SCOTT
dealer and ask him to explain the system of your SCOTT bike to you.
After wheel mounting test the brakes in stationary. You should reach the
pressure point of the brake before the brake lever reaches the handlebars.
In the case of hydraulic brakes pump them, if necessary, until you reach a
precise pressure point (f).
SAFETY INSTRUCTIONS
Before mounting or replacing a fork/wheel combination with thru-axle
system, be sure to read first the manuals of the respective fork or wheel
manufacturer. More information are also provided at www.dtswiss.com
