GB-3
After pairing, turn on the docking station and use the number buttons (1,…8, ALL)
on the remote control of docking station to select the group of your choice and
use the or button to turn on/off the speaker sound or adjust the light of the
LED light. Note:
• For pairing, the docking station must be in standby mode and the devices must
be switched on.
• The group number is assigned according to the sequence of pairing. Number
“1” will be assigned to the first paired group.
• First and second paired speakers in the same group are set to left and right
channels respectively.
• Each group can contain maximum two sets LED light with speaker.
• In case pairing is not successful, use a sharp object to press and hold the PAIR
button more than 10 seconds at the bottom of the docking station for resetting
in standby mode. Then, repeat the pairing operation mentioned above.
MAINTENANCE
Care and maintenance
To clean the casing, unplug the unit and wipe off dust and stains with a soft,
damp cloth. Do not use benzene, thinner or similar chemicals to clean the casing.
If at any time in the future you want to dispose of this product, please
note that electrical products should not be disposed of with household
waste. Find out where your nearest recycling centre is. Consult your
local authority or retailer for more details (Waste Electrical and
Electronic Equipment Directive).
TROUBLESHOOTING GUIDE
Problems Recommendations
1. The LED light with
speaker does not work
properly
1.1 Do pairing.
1.2 Do not use your external dimmer control.
TECHNICAL SPECIFICATIONS
LED light with speaker
Power source AC 100-240V ~ 50/60Hz
Light type LED, E27 screw
Lighting power 5 W
Light life 30000 Hours
Speaker 2.25”, 4 Ohm
Output power – Speaker 10 W (r.m.s.)
Power consumption 20 W (Light + speaker)
Standby power consumption < 1 W
Dimensions 138 (H) x 85 (Dia) mm
Weight 0.4 Kg
Note: Due to continuing improvements, the technical specifications are subject
to change without notice.
