SCOTT LUMEN 2023 - Page 2

2023 LUMEN eRIDE | ENGLISH 2
|
LUMEN eRIDE
GEOMETRY & TECHNICAL DATA 03
HEADSET ADJUSTMENT 05
SETTING SAG 06
TWINLOC 07
TQ SYSTEM MANUALS 07
CABLE ROUTING 08
SPARE PARTS 11
MANUFACTURE’S GUARANTEE 15
LEGEND
T 2
10 Nm
TORQUE REQUIRED
TORX TOOL SIZE
HEX TOOL SIZE
TORQUE AMOUNT
TASK DIFFICULTY
NO GREASE REQUIRED
GREASE REQUIRED
CARBON GREASE REQUIRED
THREADLOC REQUIRED
CONTENT
THE LUMEN eRIDE SHOULD BE ADJUSTED EXACTLY TO THE RIDER FOR MAXIMUM SAFETY AND
RIDEABILITY.
Please contact your authorized SCOTT dealer for advice in order to avoid technical problems or any harm.
BEARING FIT REQUIRED
