SCOTT PATROL E2 Series - Page 4

|
4 ENGLISH
11
1
2
3
8
5
7
6
4
4
4
4
8
9
9
10
11
12
LEGEND
Compressor compartment
Trigger handle
LCD display (see section X.C.)
Super capacitors
2 x AA Battery compartment
(batteries not included)
USB-C port (cable included)
ON / OFF switch
3 x LED (see section X.B.)
Trigger cable
Deflation knob
Air inlet
Compressor case and wheel
Deflation button cover
Pressure relief valve
(see section X.D.)
ENGLISH
WINTERSPORTS ALPRIDE E2 AIRBAG SYSTEM
