ENGLISH -6
7- ENGLISH
Model identification
C. FURTHER MARKINGS
Below you can find each product is marked on the inside of the frame with a
reference code. The model description of each code :
2301 SCOTT REACT
2250 SCOTT SPLIT OTG
2201 SCOTT FACTOR
2101 SCOTT SHIELD
2001 SCOTT VAPOR
1701 SCOTT WITTY
1702 SCOTT FAZE II
1601 SCOTT UNLIMITED II OTG
1602 SCOTT MUSE PRO
1603 SCOTT MUSE
1604 SCOTT MUSE PRO OTG
1501 SCOTT LCG COMPACT
1502 SCOTT FIX
1401 SCOTT LINX
1301 SCOTT LCG EVO
1203 SCOTT FACT
1250 SCOTT HABIT OTG
1104 SCOTT AGENT
0601 SCOTT 89X (CLASSIC, ASSET, ALTA)
D. SCOTT WINTER GOGGLE LENSES
MARKETING NAME TINT CAT. REF
AMPLIFIER
LIGHT SENSITIVE
Light Sensitive Blue Chrome S2-S4 L154, L365
Light Sensitive Bronze Chrome S1-S3 L155, L354
Light Sensitive Red Chrome S2-S3 L162, L362
SOLAR BLOCKER
Solar Black Chrome S3 L156, L355
Solar Red Chrome S3 L158, L368
Solar Blue Chrome S3 L102
ENHANCER
Enhancer Aqua chrome S2 L165, L367
Enhancer Blue chrome S2 L163, L363
Enhancer Rose chrome S2 L164, L364
Enhancer Purple Chrome S2 L113, L322
Enhancer Silver Chrome S2 L114, L312
Enhancer Teal Chrome S2 L116, L356
Enhancer Red Chrome S2 L151, L350
Enhancer Green Chrome S2 L110
AMPLIFIER
Enhancer Yellow Chrome S2 L357, L159
Enhancer S2 L119, L505, L711
ILLUMINATOR
Illuminator S1 L120, L501
Illuminator Red Chrome S1 L153
Illuminator Blue Chrome S1 L161, L361
OTHERS COLORS
Night Enhancer S1 L559
Clear S0 L152, L504
The resistance to fogging is guaranteed on all SCOTT winter goggles
Light transmission curves are available at www.scott-sports.com.
• V. TIME OF OBSOLESCENCE
SCOTT Goggles have limited lifespan. For optimum safety, SCOTT recom-
mends replacing your product three (3) to five (5) years after its purchasing
date, depending on usage.
SCOTT Goggles or goggle lenses that are damaged or worn out must be
replaced for safety reasons.
SCOTT shall not be liable for damages relating to the use of products which
should have been replaced.
It is essential for the lens to be changed if it can no longer be guaranteed to
work properly and provide good protection because of soiling, mechanical
wear and tear or improper usage.
• VI. INSTRUCTIONS FOR SIZING, FIT
For the SCOTT product to serve its purpose, it must cover the protected area
correctly.
To obtain maximum comfort and protection, SCOTT goggles must be adjust
-
ed correctly.
The goggles should be placed on the user’s face, and the strap around the
head or the helmet. Adjust the strap by sliding the plastic sliders towards the
face to tighten it, and towards the back of the head to loosen it.
A. CHANGING THE LENS
Please note that ideally the lens should be changed at room temperature so
that the frame is sufficiently pliable.
Should you need a new lens, please make a note of the model code, which
is marked inside the frame (IV. Product Information) and order the relevant
replacement lens from your specialist retailer.
All goggles ( excluding frames 1301, 1501, 2301)
1- Remove the lens from the frame by pulling the nose section away from
the lens (1) and remove the lens it from each of the mounts.
2- When inserting the new lens, press the nose section together and insert
the lens into the nose groove so that the mount engages.
3- Repeat the process on the lower (2) and on the upper edge (3) of the
goggles.
4- Be sure that the entire lens is properly seated in the frame slot and all
frame retention posts are fully engaged with the lens keyholes. If this is
not the case, apply slight pressure to click it into place.
1
2
2
3
3
