6. Assembly
6.1 Assembly of the SCR-E model
1. Carefully remove the bike from the packaging, then
remove all protective material, being careful not to
scratch the painted parts and pull the bike cables. The
removal of the bike from its packaging must be an
operation carried out by two adult persons in order to
avoid injuries or crushing.
2. Insert the upper part of the handlebar stem (labelled
number 1) inside the lower part of the handlebar stem
(labelled number 2). Adjust the height of the handlebar
stem according to your riding preferences.
3. Position the handlebar stem in a vertical position, then
tighten the handlebar using the specific lever on the
handlebar stem.
4. Orient the seat and tighten the seat post correctly
using the seat collar on the frame (photo on the right).
Do not raise the seat tube beyond the limit
indicated on the seat post to avoid breaking the
frame and serious injuries while riding.
1
2
12
