10
13mm
CAUTION: Leave the Left Box laying on its side for a future step
and until attaching the Center Box.
LEFT
Swing Door
with
shelves
Remove spacer shelves now and set aside.
13mm Euro Screws
x18
14
Turn box onto Side 2.
Install 5 offset hinges to Left Box Side 1
panel using (15) 13mm Euro Screws.
With two people, attach Left Swing Door with Shelves
to Left Box Side 1 using (15) 13mm Euro Screws.
Left Box
Side 1
Barrel faces down
so that short side of
hinge drops down
below edge of Right
Box.
SHORT SIDE Attaches to
Left Swing Door with Shelves
LONG SIDE Attaches to
Left Box Side 1
It is SAFE to use
an Electric Screw Driver
to intall hinges.
To Next Page
