29
Left
Box
LEFT, RIGHT & CENTER BOXES
27
Rotate Left & Right boxes doors down.
Use 24 washers screws to attach
6 angle brackets to the base of each box.
14mm
Washer Screws
x24
Angle Brackets
x6
Right
Box
Center
Box
It is SAFE to use
an Electric Screw Driver
to intall hinges.
**CAUTION: if electric screw driver
is used, DO NOT OVER-TIGHTEN.
You risk stripping your screws.
To Next Page
