ScrapBox WorkBox 3.0 - Page 30

30
CENTER BOX
28
Install both table legs
by lining up pilot holes.
Lift table leg and attach using (8)
3/4” Table Leg Screws.
3/4” table
leg screws
x8
Use (9) 13mm Euro Screws
to install (3) Hinges with
barrel facing out to
bottom side of table.
29
With TWO PEOPLE,
use (9) 13mm Euro Screws
to attach table to
Center Box.
30
31
13mm
Euro Screws
x9
13mm
Euro Screws
x9
13mm
Euro Screws
x30
Use (15) 13mm Euro Screws to attach (5) Hinges to Center Box Side 1.
Repeat for Side 2 using (15) more 13mm Euro Screws and (5) more Hinges.
Hinges
x10
Hinges
x3
It is SAFE to use
an Electric Screw Driver
to intall hinges.
