31
OPTIONAL: If you did not purchase a crown, install sash lock on left and right box
using (4) 14mm Self-tapping screws.
LEFT BOX
RIGHT BOX
CENTER BOX
33
32
13mm
Euro Screws
x30
With TWO PEOPLE carefully lift the Center Box and place against wall.
Lift and attach Left and Right Box one at a time.
**CAUTION: Move slowly! Center box is very heavy!
Use (15) 13mm Euro Screws
per side to attach Left Box and
Right Box to Center Box hinges.
Use (2) 1”Screws to attach both
door handles.
x1
Door Knob
1” Screw
(or x2 for Ergo White)
(or x1 door handle
for Ergo White)
x1
for attaching ScrapBox Security Kit
included in your hardware
It is SAFE to use
an Electric Screw Driver
to intall hinges.
