SPECIFICATION OF POWER ADAPTER
Input: 100-240V AC, 0.35A MAX, 50-60Hz Output: +5V DC, 2A
CARE & MAINTENANCE
To troubleshoot, please visit: Scrib3dPen.com/troubleshooting
LIMITED WARRANTY
For more details on your limited warranty, please visit:
scrib3dpen.com/warranty
For Scrib3D Terms and Conditions and other notices refer to our
website: scrib3dpen.com/terms-and-conditions
For care and maintenance information, and more advice on how to
use your Scrib3d P1, please refer to our website: Scrib3dPen.com
FCC
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Warning: Changes or modifications to this unit not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION: This Class B digital apparatus complies with Canadian
ICES-003
CAN ICES-3 (B)/NMB-3(B)
Manufactured by SCRIB3D LLC, and distributed by SCRIB3D LLC and
WobbleWorks, Inc. Address: 89 5th Avenue, Suite 602, NY, NY, 10003.
This product is protected by SCRIB3D LLC and WobbleWorks, Inc.
intellectual property. Please see the list of applicable WobbleWorks’
patents at http://PiKA3D.com/patents. PIKA3D is a trademark owned
by WobbleWorks, Inc. The PIKA3D pika character icon is the
copyrighted property of WobbleWorks, Inc. © SCRIB3D LLC &
WobbleWorks, Inc.
Designed in the USA.
Made in China, Guangdong.
ISSUES?
Before returning to the
retailer see if we can help
Check out our tutorials:
SCRIB3dPen.com/tips
Need more help? Contact us
help@SCRIB3dPen.com
We recommend only using the
Reverse button when removing
and changing lament. If only
partially withdrawn, lament
can swell in the pen and create
jams. If this happens, fully
withdraw the lament and cut
the swollen part o.
Filament quality varies greatly.
We always recommend using
Scrib3D lament, and storing it
in a sealed and dry location.
Plastic may continue to
ooze slightly after the
pen stops. This is more
pronounced with PLA.
This is a common
Phenomenon (i.e. glue
guns and 3D printers). If
you see this happening,
slightly decrease the
temperature.
When using your
Scrib3D P1 3D Pen you
will nd the best
results for drawing at
object and on surface
from holding the pen
at an angle of 65
dagrees or higher.
Snip those tips! when you change plastic or before
you insert a new strand make sure the lament has
a at surface so it can push the previous lament.
Failure to cut the end o the plastic can result in
jams or pens not extruding. Check out tips on how
to solve such issue on page 6.
Troubleshooting
Temperature Tuning
1. If when using the pen you see the plastic
bubbling or you hear a crackling noise coming
from the plastic your temperature might be too
high. Try lowering it 5~10°C and see if that
helps.
2. Filament should come out smooth and with
out much bubbling but it is normal to have
some small bubbling.
3. While some plastics like PLA are more prone
to oozing, if you nd that your oozing a lot of
plastic you can turn the temperature down on
the pen to help mitigate this. Also check that
you are using the correct lament setting
4. If the lament color looks dim and dark and
you can hear the motor struggling. This means
the temperature is too low increase the
temperature by 5~10°C.
For more help getting started, tips
and tricks, trouble shooting and to
learn more check out our website
www.Scrib3dPen.com or our
youtube channel (scan the QR code).
Problem Reasons Solution
Power indicator
Light will
not turn on
Issue with the AC adapter
or plug
Issue with the electronics
of the pen
Issue with the power socket
of the pen
Replace the AC adapter
with another: 5v, 2A, 3.8mm
barrel center + adapter
The pen’s electronics need
servicing please contact
help@Scrib3Dpen.com if
the pen is under warranty
Nothing is coming
out of the nozzle
The temperature is not high
enough or the wrong mode
for plastic was selected
Check mode the pen is in is
correct of the plastic you are
using. You can also try
adjusting the temp manually
Filament has stripped
ie. a chunk has been
taken out of the lament
and the drive system can’t
push it anymore
Reverse the lament out of
the pen. Cut o the damaged
portion and throw it away
and try again
Filament won’t go in
Make sure the lament has
a at surface on the end
going into the pen
No motor noise
Possible issue with the
electronics or the motor.
Please contact us at
help@Scrib3Dpen.com
Pen not heating up
Probem with the heating
element/nozzle
Motor is struggling
Could be an issue with the
lament inside
Reverse out the lament. Cut
o any swollen or deformed
parts and cut a new end
before reinserting.
NOTE: Your pen will go into sleep mode after being inactive for 5
minuts (as a safety feature). Click any button to wake it up and
restart the heating sequence.
Here are some common problems and possible solutions to these
issue. If you can’t resolve the issue please reach out to our
customer service by email us at help@Scrib3Dpen.com
This marking indicates that this product should not be
disposed of with other household wastes. To prevent
possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources.
Please contact
customer service at
help@Scrib3Dpen.com
