SEA BEYOND INT’L T-REX User Manual

4. Attach the handlebar ends with the
thumb screws. See the photo so you put the
right end on the right side. Note: The front
axle is pointing backwards as packed.
5. Attach seat post and seat. Insert the seat
post fully into the sleeve until it hits the
bottom, then tighten the strap. Remove the
scooter from the box by lifting the seat post
and handlebars. Turn handlebars forward
and lay the scooter on its right side (side
opposite the engine).5mm hex wrench
needed.
7. Put the kickstand down and bring the
scooter upright. Attach the gas tank with
the two hex bolts. Slide the hose springs
closer to the gas tank and route the hoses so
that they aren't in the way of any moving
parts (chain, wheel, etc.). Also make sure
they are not pinched. 8mm hex wrench
needed.
8. Adjust the brakes by tightening the adjustments at both ends of the brake cable until
the wheel still rolls but the brake works well. See the “Brake Adjustment Guide”
9. Adjust chain. See the “Chain Adjustment Guide”
10. Adjust Carburetor if needed. See the “ Carburetor Adjustment Guide”
11

SEA BEYOND INT’L T-REX Specifications

General

Brand	SEA BEYOND INT’L
Model	T-REX
Category	Scooter
Language	English
