Figure 5 Mounting Dimensions (for 2-disk models)
100.35
+
-
0.20
0.25
69.850
0.250
22.450
16.520
7.949
1.270
2.499
1.270
(90.600)
(14.000)
2X (3.000) BOTH SIDES
7.000
0.200
2X M3 X 0.5-6H
MOUNTING HOLES: BOTH SIDES
3.505 +.075 -.3 X90
BASE
(13.430)
(3.)
