DB35.3 Series PATA Product Manual, Rev. C 25
Figure 6 Mounting dimensions—top, side and end view
Notes:
1. Dimensions are shown in inches (mm).
2 Dimensions per SFF-8301 specification.
3 x 6-32 UNC-2B
0.150 (3.81) max. fastener
penetration both sides. 3 threads
minimum engagement.
R
ecommended
c
ase temperature
m
easurement location
0.1240 0.01
(3.18 0.25)
3.750 0.01
(95.25 0.25)
4.0 0.01
(101.60 0.25)
Recommended
case temperature
measurement location
4 x 6-32 UNC-2B
0.150 (3.81) max. fasten
er
penetration. 3 threads
minimum engagement.
1.75 0.01
(44.45 0.25)
1.625 0.020
(41.28 0.51)
4.0 0.01
(101.60 0.25)
5.787 max
(146.99)
1.638 0.01
(41.61 0.25)
1.122 0.02
(28.5 0.51)
3 x 0.25 0.010
(6.35 0.037)
both sides
1.028 max
(26.11)
0.228
(5.79)
0.178
(4.27)
2.23
(56.56)
2.83
(71.80)
3.71
(94.35)
2
